Important information to read before installing and / or using a dimmer rack.
DIGILIGHT - SHOWRACK touring range
Exemples of configurations
- SR65P17 : 1 x DP65.P17 module + 1 distribution module on the front panel, outputs on 6 x P17 on rear panel.
- SR123.PC : 2 x DP65.P17 module + 1 distribution module on the front panel, outputs on 24 x P17 on rear panel.
- SR483.PC : 4 x DP65.PC module, 1 distribution module on the front panel, outputs on 48 x double power sockets + 1 x distribution module with 10 Camlock sockets on the rear panel.
Modèles standards disponibles :
SR65.P17 : 6x5kW, 1xP17 per channel, flight case 7U
SR122.PC : 12x2,4kW, 2xPC per channel, flight case 7U
SR122.PS : 12x2,4kW, PAR64 serial patch, flight case 7U
SR123.PC : 12x3kW, 2xPC per channel, flight case 7U
SR125.P17 : 12x5kW, 1xP17 32A per channel, flight case 12U
SR242.PC : 24x2,4kW, 2xPC per channel, flight case 12U
SR242.PS : 24x2,4kW, PAR64 serial patch, flight case 12U
SR243.PC : 24x3kW, 2xPC per channel, flight case 12U
SR482.PC : 48x2,4kW, 2xPC per channel, flight case 12U
SR482.PS : 48x2,4kW, PAR64 serial patch, flight case 20U
SR483.PC : 48x3kW, 2xPC per channel, flight case 20U
Showrack - SR123.PC
Showrack - SR65.P17
Technical specifications of the modules :
Showrack is composed with DIMMERPACK power module
TECHNICAL SPECIFICATIONS
- Composed of 1, 2 or 4 DIMMERPACK modules
- Power supply:
1 x P17 63A plug up to 125A per phase
1 camlok connector beyond 125A per phase
- 1 dual direct drive circuit breaker protected
-DMX512 remote input :
With DMX512 digital patch function
- In flight case
OPTION
Analog 0/10V input
Especially manufactured for intensive use - Ready to use, in flight case.
Security standards :
According to the electrical standards, it is necessary to establish a differential switch or a 30 mA circuit breaker in each portable block dimmer. A slot is provided for this purpose on each model.
